This is a Negative Voltage Converter circuit. This is the most popular application that use the MAX1044/ICL7660. This circuit just requires two external capacitors. It is recommended if the circuit is added by A third power-supply bypass capacitor with value range 0.1
Read moreDC/DC step-up converter is applicable on battery-powered equipment. DC/DC step-up converter can be used to generate supply voltages for internal circuits that require higher voltages than the available battery voltage. There’s two kind of converters, inductive and capacitive. Inductive step-up converters have a high efficiency over the entire input voltage range. Capacitive converters-i.e., charge pumps give us a high efficiency […]
Read more
This is a circuit that can provide -12 V negative supply from positive supply. The output voltage is Vo= -Vin· D/(1-D). The maximum output current is Iout=1·(1-D). Here is the circuit : In this circuit, the ground of U1 is connected to negative output voltage. The input voltage of U1 must be lower than maximum operating input voltage, 36V, because […]
Read more
This is positive buck-boost regulator circuit. Using this circuit, we can implement a step-down/up converter with a positive output voltage. This circuit produces an output voltage of 12 V. Here is the circuit : This circuit requieres input voltage between 5 V and 35V. The output voltage is given by Vo=Vin·D/(1-D). The maximum output current is Iout=1x(1-D). The term (1-D) […]
